The Bluesun 125kw string inverter is compatible with high-power modules and so are perfect for commercial installations. It’s lightweight build makes it easy to carry out one-person installations. 8 MPPTs allow for better and more flexible plant design. With a 40A MPPT current input the inverter follows the latest market trends and is compatible with over 500Wp PV modules.
| Model: | BSM125K-B |
| Type: | PV On-Grid String Inverter |
| Max Power: | 125KW |
| Max. Efficiency: | 98.7% |
| Communication: | RS485/Wifi/4G |
| Warranty: | 5 Years(10 Years Option) |
| Certificate: | CE/TUV/EN50549/VDE4105/VDE0126 |
Bluesun three-phase on-grid inverter power range is from 3kW to 125kW with 230/400Vac. So, it can connect to utility grid(230/400V) directly without transformer. All the inverters are equipped with LCD display and buttons, easy operation and maintenance specially for remote and poor areas.
High Efficiency:
99% max efficiency, dual MPPT, and compatibility with 182/210 PV panels.
Reliable:
Natural/smart cooling, voltage protection, and built-in lightning protection.
User-Friendly:
Operates at 100% rated power under 45℃ with convenient app support.
PV Voltage Up To 1100v
Type II DC /AC SPD
DC/AC Ratio Up To 1.5
IP66 Protection
PLC communication
WiFi / 4g Plug Optional
High Efciency Up To 98.7%
Smaller And Lighter
